Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras

More Views

Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras

Availability: In stock

Lorex 16-Ch 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras
  • Item Part#: DK162-88CA-R
  • Mfg Part#: DK162-88CA
  • Manufacturer: LOREX
  • Warranty: 90 Days
  • Condition: Refurbished
  • Free Shipping: Yes
$514.99
Description

Details

Additional Information:

These Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras are in great working condition. The unit has been fully tested and is completely functional.



Included in the Box:

  • Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras
  • 4K UHD DVR with 2TB HDD
  • HDMI Cable
  • Ethernet Cable
  • DVR Power Adapter
  • USB Mouse
  • 8 x Lorex C841CA-E 4K UHD Outdoor AHD Bullet Camera with Color Night Vision
  • 8 x Mounting Kits
  • 8 x 60' BNC/DC Extension Cables
  • 8 x Power Adapters for Cameras



Packaging:

The item is securely packaged in Original box.



Key Features:
  • Record from and Manage up to 16 Cameras
  • 4K UHD Recording Resolution per Camera
  • 2TB Preinstalled HDD
  • Two-Way Audio Communication
  • 8 x 4K AHD Bullet Cams Included
  • 82' of Night Vision in Total Darkness
  • 87° Horizontal Field of View
  • Lorex Home App for iOS and Android
  • IP67-Rated Cameras



Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras Description:

Monitor your property with the 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras from Lorex. This DVR comes preinstalled with a 2TB HDD. Storage is expandable to 10TB. Space-saving H.265 and H.264 video codecs reduce bandwidth requirements for efficient data storage while maintaining the best quality possible. The Lorex Home app enables remote viewing from an iOS or Android device, along with Windows and Mac PCs.

The included IP67-rated bullet cameras use 1/3" CMOS sensors to transmit 3840 x 2160 resolution video at 15 fps. IR LEDs provide a night vision range up to 82' in total darkness and 120' in ambient lighting. The cameras feature a 3.6mm fixed lens that delivers an 87° horizontal field of view.



DVR Features
  • Voice control via Amazon Alexa and Google Assistant
  • Streaming options include Chromecast, Apple TV, Amazon Echo Show, and Google Home Hub (available separately)
  • Smart Search
  • Person/vehicle motion detection for the first four channels
  • H.265 and H.264 video compressions
  • Panic button is located on the recorder to activate all lights and sirens on compatible cameras
  • HDMI and VGA video outputs
  • RCA audio input and output
  • 100M RJ45 Ethernet port
  • Remote viewing via Lorex Home app
  • 24/7 security-grade preinstalled 2TB HDD
  • HDD storage expandable to 10TB
  • Digital zoom
  • Optional DDNS support
Bullet Camera Features
  • AHD transmission
  • Color Night Vision technology
  • Night vision up to 82' in complete darkness and up to 120' in ambient lighting
  • NTSC format
  • -40°F cold start
  • IP67-rated and vandal-resistant polycarbonate enclosure with cable conduit



Lorex 16-Channel 4K UHD DVR with 2TB HDD & 8 4K Outdoor Night Vision AHD Bullet Cameras Specifications:

DVR
Transmission Technology
Analog HD
Channels
16
Video Inputs
16 x 1 V p-p, CVBS, 75 Ohms, BNC
Video Outputs
1 x VGA
1 x HDMI
Audio
1 x RCA Input
1 x RCA Output
Display Output Resolution
Up to 4K UHD
Live Display
1, 4, 8, 9, 16
Live Display Speed
NTSC: 480
PAL: 400
OSD
On/Off
System Navigation
USB Mouse
Recording Resolution
8 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p
Recording Frame Rates
8 MP at 7 fps, 5 MP at 12 fps, 4 MP at 15 fps, 3 MP at 15 fps, 1080p at 30/25 fps (NTSC)
Recording Schedule
By Recording Mode (Continuous, Motion)
By Advanced Motion (Person, Vehicle)
By Alarm
By Day
By Hour
Backup File Format
DAV, AVI, MP4
Video Compression
H.265, H.264
Simultaneous Playback
Up to 4 Channels
Playback Speed
Variable, Maximum 16x
Search
By Time/Date, All Motion Events or Smart Motion (Person, Vehicle), Area Search (Smart Search)
HDD Bay
1
HDD Capacity
1 x 10 TB (SATA)
HDD Included
2 TB
Backup Media
USB Flash Drive and USB HDD
Motion Detection
Person/Vehicle Smart Motion Detection (Enabled Only on Channels 1-4)
Smart Search
Supported
Voice Control
Amazon Alexa, Google Assistant
Streaming Options
Chromecast, Apple TV, Amazon Echo Show, Google Home Hub
Mobile App
Lorex Home for iOS and Android
Remote Viewing Options
Lorex Home for iOS, Android, Windows & Mac PCs
Email Notification
Text and Snapshot
Network Interface
100M RJ45
DDNS
Optional
USB Interface
2 x USB 2.0
Firmware Upgrades
USB, Network
Watchdog Function
Yes
Power Consumption
<10 W without HDD
Supply Voltage
12 V, 2 A
Operating Temperature
14 to 131°F / -10 to 55°C
Humidity
10 to 90% RH
Dimensions
12.9 x 9.6 x 2.1" / 328 x 245 x 53 mm
Weight
2.75 lb / 1.26 kg without HDD
Bullet Camera
Transmission Technology
AHD
Image Sensor
8 MP 1/3" CMOS
Video Format
NTSC
Field of View
Horizontal: 87°
Lens
3.6mm Fixed
Aperture
f/2.0
Effective Pixels (H x V)
3840 x 2160
Resolution
8 MP at 15 fps
Termination
BNC Type
Night Vision Range
Complete Darkness: 82' / 25 m
Ambient Lighting (Color Night Vision): 120' / 37 m
Power Requirements
12 VDC ±10%
Maximum Power Consumption
346 mA / 4.15 W
Operating Temperature
-40 to 131°F / -40 to 55°C
Humidity
<90% RH
Housing Material
Polycarbonate
IP Rating
IP67
Dimensions
2.8 x 6.2 x 2.8" / 70 x 158 x 70 mm
Weight
0.65 lb / 0.3 kg
