- Description
-
Details
Additional Information:
This Cisco Managed Switch is in great working condition.
The unit has been fully tested and is completely functional.
Included in the Box:
Cisco Managed Switch, power cord, console cable, documentation, software CD, rack mount kit.
Packaging:
The item is securely packaged in Original box.
Brand: Cisco
Model: SG500-52P-K9-NA
Features:
- The SG500-52P Port Stackable Managed Switch from Cisco provides advanced capabilities to support a more demanding network environment at an affordable price. It is designed to protect your technology investment as your business grows. The Cisco 500 Series provides true stacking capability which allows you to configure, manage and troubleshoot multiple physical switches as a single device and more easily expand your network.
Specifications:
Switching Capacity 120 Gb/s PoE Power Dedicated to PoE: 375 W
Number of Ports that Support PoE: 48Power Consumption 110 V/0.647 A/63.7 W
220 V/0.405 A/64.7 W
Green Power Mode: EEE + Short Reach + Energy Detect
Heat Dissipation: 203.3 BTU/hrPorts Total Ports: 48 GE + 4 GE (5 G stacking)
RJ-45 Ports: 48 GE
Combo Ports (RJ-45 + SFP): 2 combo GE + 2 1 G/5 G SFPButton Reset button Cabling Type Unshielded Twisted Pair (UTP) Category 5 or better
Fiber options (SMF and MMF); Coaxial SFP+ for stacking purposesLEDs LED power savings, System, Link/Act, PoE, Speed Flash 32 MB Memory 800 MHz ARM, 256 MB (CPU memory) Packet Buffer 2 x 8 Mb Connection Stack Connection:
5 G copper - SFP-H10GB-CUxM
1 G fiber or copper - MGBxxx
1 G Base-T - embedded RJ-45 (S1/S2)Power 100 to 240 V
47 to 63 Hz; internal, universalOperating Temperature 32 to 104°F (0 to 40°C) Storage Temperature -4 to 158°F (-20 to 70°C) Operating Humidity 10 to 90%; relative, non-condensing Storage Humidity 10 to 90%; relative, non-condensing Cooling Fan No of Cooling Fans: 4
Fan Speed: 5000 rpmAcoustic Noise 86°F (30°C) = 41.1 dB
104°F (40°C) = 54.8 dBMTBF 143, 124.8 hr @ 104°F (40°C)
105, 252 hr @ 113°F (45°C)Requirements Web Browser: Mozilla Firefox version 8 or later; Microsoft Internet Explorer version 7 or later, Safari, Chrome
Category 5 Ethernet network cable
TCP/IP, network adapter and network operating system (such as Microsoft Windows, Linux or Mac OS X) installedStandards IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet,
IEEE 802.3ad Link Aggregation Control Protocol, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.3 ad LACP,
IEEE 802.1D (STP, GARP and GVRP), IEEE 802.1Q/p VLAN, IEEE 802.1w Rapid STP, IEEE 802.1s Multiple STP,
IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879,
RFC 896, RFC 826, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 922, RFC 920, RFC 950, RFC 951, RFC 1042, RFC 1071,
RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC 1350, RFC 1533, RFC 1541, RFC 1542, RFC 1624, RFC 1700, RFC 1867, RFC 2030, RFC 2616,
RFC 2131, RFC 2132, RFC 3164, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC 2576, RFC 4330, RFC 1213, RFC 1215, RFC 1286,
RFC 1442, RFC 1451, RFC 1493, RFC 1573, RFC 1643, RFC 1757, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2233, RFC 2618,
RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 1157, RFC 1493, RFC 1215, RFC 3416Certification UL (UL 60950)
CSA (CSA 22.2)
CE mark
FCC Part 15 (CFR 47) Class ADimensions (W x H x D) 17.3 x 1.7 x 13.7" (44 x 4.4 x 35 cm) Weight 12.36 lb (5.61 kg) - Reviews
-
